G200V Performance Curve
G200V Noise curve
G200V Performance Table
| RPM | -1000mmAq | -2000mmAq | ||
| Qs | La | Qs | La | |
| 600 | 17.52 | 4.91 | 16.47 | 9.41 |
| 750 | 23.36 | 6.14 | 22.31 | 11.75 |
| 900 | 29.2 | 7.38 | 28.15 | 14.11 |
| 1050 | 35.04 | 8.61 | 33.99 | 16.46 |
| 1200 | 40.88 | 9.84 | 39.83 | 18.81 |
| 1350 | 46.72 | 11.06 | 45.67 | 21.16 |
| 1500 | 52.56 | 12.29 | 51.51 | 23.52 |
| RPM | -2500mmAq | -3000mmAq | ||
| Qs | La | Qs | La | |
| 600 | 15.88 | 11.51 | 15.31 | 13.52 |
| 750 | 21.72 | 14.38 | 21.15 | 16.9 |
| 900 | 27.56 | 17.27 | 26.99 | 20.28 |
| 1050 | 33.4 | 20.14 | 32.83 | 23.67 |
| 1200 | 39.24 | 23.01 | 38.67 | 27.05 |
| 1350 | 45.08 | 25.89 | 44.51 | 30.43 |
| 1500 | 50.92 | 28.77 | 50.35 | 33.81 |
| RPM | -3500mmAq | -4000mmAq | ||
| Qs | La | Qs | La | |
| 600 | 14.64 | 15.46 | 13.89 | 17.32 |
| 750 | 20.48 | 19.33 | 19.73 | 21.64 |
| 900 | 26.32 | 23.18 | 25.57 | 25.97 |
| 1050 | 32.16 | 27.05 | 31.42 | 30.3 |
| 1200 | 38 | 30.92 | 37.26 | 34.63 |
| 1350 | 43.84 | 34.77 | 43.1 | 38.96 |
| 1500 | 49.68 | 38.64 | 48.94 | 43.29 |
| RPM | -4500mmAq | -5000mmAq | ||
| Qs | La | Qs | La | |
| 600 | 13.16 | 19.1 | 12.34 | 20.82 |
| 750 | 19 | 23.87 | 18.18 | 26.02 |
| 900 | 24.84 | 28.65 | 24.02 | 31.23 |
| 1050 | 30.68 | 33.42 | 29.86 | 36.43 |
| 1200 | 36.52 | 38.2 | 35.7 | 41.64 |
| 1350 | 42.36 | 42.98 | 41.54 | 46.84 |
| 1500 | 48.2 | 47.76 | 47.38 | 52.05 |
G200V Outline Dimensions
| No. | Item | Material |
| 1 | gear box 齿轮箱 | FC250 |
| 2 | gear box 齿轮 | SCM415 |
| 3 | bearing 轴承 | SUJ2 |
| 4 | bearing case 轴承座 | FC250 |
| 5 | side cover 侧盖 | FC250 |
| 6 | oil plug 加油塞 | S45C |
| 7 | lmpeller 叶轮 | FC250 |
| 8 | eye bolt 吊环 | S45C |
| 9 | shaft seal 轴封 | S45C |
| 10 | oil box 油箱 | FC250 |
| 11 | oil splash 甩油片 | SS400 |
| 12 | oil seal case 油封座 | FC250 |
| 13 | screw nut 螺帽 | SS400 |
| 14 | pulley 皮带轮 | FC250 |
| 15 | oil seal case 油封 | NBR |
| 16 | oil gauge 油镜 | S45C |
| 17 | oil drainer 泄油塞 | S45C |
| 18 | cylinder 汽缸 | FC250 |
| 19 | shaft 轴 | SCM440 |
| 20 | oil gauge 油镜 | S45C |
| 21 | oil drainer 泄油塞 | S45C |
| 22 | oil splash 甩油片 | SS400 |
G200V Outline Dimension
